Advanced DPSS Technology for Superior Performance in Precision Applications
Our DPSS laser modules combine cutting-edge diode-pumped technology with solid-state lasers to deliver unparalleled precision, stability, and efficiency. Designed for applications where consistent performance is critical, these modules are ideal for industrial, scientific, medical, and research settings. Featuring low divergence, excellent beam quality, and high optical power, DPSS lasers provide optimal performance for tasks such as spectroscopy, laser marking, medical treatments, and more. With a range of wavelengths and customizable options, these modules are engineered for long life and reliability, making them the perfect choice for demanding professional environments.
Filters Sort results
Reset Apply
Part Number | Product Line | Wavelength | Output Power | Beam Divergence | Operating Current | Operating Voltage | Modulation | Operating Temperature | Mechanical Dimensions | |
|---|---|---|---|---|---|---|---|---|---|---|
 | Laser Modules - DPSS Laser Modules | 532nm | From <1mW up to <5mW | <1.2mrad | 140mA | 3VDC | 20°C to 28°C | Dia. 8mm x L. 50.7mm | ||
 | Laser Modules - DPSS Laser Modules | 532nm | From <1mW up to 20mW | <1.2mrad | <0.30A | 3VDC | 20°C to 30°C | Dia. 12mm x L. 47.3mm or 51.3mm | ||
 | Laser Modules - DPSS Laser Modules | 532nm | From <1mW up to 20mW | <1.2mrad | <0.30A | 3VDC | 20°C to 30°C | Dia. 13mm x L. 52mm | ||
 | Laser Modules - DPSS Laser Modules | 532nm | <1mW | <1.2mrad | <0.30A | 3VDC | 20°C to 30°C | Dia. 12mm x L. 55.3mm | ||
 | Laser Modules - DPSS Laser Modules | 532nm | From <1mW up to 20mW | <1.2mrad | <0.30A | 9-15VDC | TTL up to 1kHz | -22°C to 28°C | Dia. 20mm x 58.5mm (Laser head) | |
 | Laser Modules - DPSS Laser Modules | 532nm | From <1mW up to 20mW | <1.2mrad | <0.30A | 3VDC ⋅ 5VDC | 20°C to 30°C | Dia. 20mm x L. 60mm | ||
 | Laser Modules - DPSS Laser Modules | 532nm | From <1mW up to 20mW | <1.2mrad | <0.30A | 3VDC ⋅ 5VDC | 20°C to 30°C | Dia. 20mm x L. 70.5mm | ||
 | Laser Modules - DPSS Laser Modules | 532nm | From <1mW up to 20mW | <1.2mrad | <0.30A | 9-15VDC | 20°C to 30°C | 50mm x 21mm x 21mm (Laser head) | ||
 | Laser Modules - DPSS Laser Modules | 532nm | From <1mW up to 50mW | <1.5mrad | <0.3A for <5mW | 20°C to 30°C | 50mm x 50mm x 34mm (Laser head) | |||
 | Laser Modules - DPSS Laser Modules | 1064nm | From <5mW to 100mW | <1.4mrad | <0.4A for <5mW | 9-15VDC | TTL up to 1kHz | 22°C to 28°C | 50mm x 21mm x 21mm (Laser head) | |
 | Laser Modules - DPSS Laser Modules | 1064nm | <200mW (~180mW) | <1.4mrad | <0.75A | 9VDC | TTL up to 1kHz | 15°C to 35°C |
