2GHz InGaAs PIN Photodiode Chip in 1×N linear array with 250μm channel pitch, low dark current, optimized for fiber optic communication.
PDAx-13A2G
Description
The Lasermate PDAx-13A2G is a high-speed InGaAs PIN photodiode chip configured in a 1×N linear array with a 250μm channel pitch (N ≥ 2), specifically optimized for fiber optic applications. The device features low dark current and low capacitance, delivering excellent sensitivity and high-speed response—ideal for multi-channel optical receivers and data transmission systems.
PDAx-13A2G – >2GHz InGaAs PIN Photodiode Chip, 1×N Linear Array
Features
- InGaAs PIN photodiode array
- 1×N linear array configuration
- Low capacitance and low dark current
- Suitable for fiber optic applications
Applications
- High speed data communication
- Gigabit Ethernet
- Fiber channel
Additional information
| Status | Active |
|---|---|
| Data Rate | >2GHz |
| Package | Bare Die |
| Number of Channels | 2, 4 |
| Active Area | Dia. 75um |
| Responsivity | 1.1A/W @ 1550nm |
| Size of Photodiode | 250um x 250um x 200um |
Documentation
Data Sheet
[PDF] PDAx-13A2G – >2GHz InGaAs PIN Photodiode Chip, 1×N Linear Array Datasheet
