The APDC-13A10G is a front-side illuminated 10Gbps InGaAs avalanche photodiode (APD) chip offering high responsivity at 1310nm and 1550nm. Designed for high-sensitivity optical detection and fiber optic applications.
APDC-13A10G
Description
The APDC-13A10G is a 10Gbps front-side illuminated InGaAs avalanche photodiode (APD) chip designed for high-sensitivity optical detection in fiber optic systems. Optimized for operation at 1310nm and 1550nm, it provides high responsivity for efficient optical signal detection and supports data rates up to 10Gbps. Its chip-level configuration is well suited for integration into high-speed optical receivers and other fiber optic applications requiring sensitive and reliable optical detection.
Features
- Front side illuminated InGaAs Avalanche photodiode chip
- High responsivity at 1310nm/1550nm
- Data rate up to 10Gbps
- High sensitivity application
- Optimized for fiber optic applications
Application
- 10Gbps fiber optic communication
- High-speed optical receivers
- High-sensitivity optical detection
- 1310nm / 1550nm fiber optic systems
- Optical networking and transmission systems
- High-speed data communication systems
Additional information
| Status | Active |
|---|---|
| PD Material/Type | InGaAs APD |
| Active Area | 45um |
| Bandwidth | 7.5GHz |
| Responsivity | 0.75A/W @ 1310nm, 0.85A/W @ 1550nm |
| Dark Current | 35nA |
| Package | Bare Die |
Documentation
Data Sheet
[PDF] APDC-13A10G — 10Gbps InGaAs Avalanche Photodiode Chip Product Datasheet
