The VCx-808C2WA is a high-performance 808nm, 2000mW VCSEL diode designed for versatility and efficiency. Packaged in a compact SMD format, it offers robust light output suitable for a wide range of applications, including sensing and illumination. Experience enhanced reliability and performance with this state-of-the-art optical solution.
VCx-808C2WA
Description
The Lasermate VCx-808C2WA is an 808nm wavelength, 2000mW output power, CW operating mode, Vertical Cavity Surface Emitting Laser (VCSEL) diode in SMD package. Ideal for 3D sensor, Lidar, IR illumination, medical, Solid state pump source, range finder sensor.
VCx-808C2WA: 808nm 2000mW CW VCSEL Diodes Data Sheet
Features
- 808nm VCSEL Diode
- Output power: 2000mW
- Single longitudinal mode
- Low wavelength drift
- Oxide isolation technology
- Small emission area
- Easy to collimate
Applications
- 3D sensor
- Lidars
- IR illumination
- Range finder sensor
- Solid-state pump source
- Medical application
Additional information
| Status | Active |
|---|---|
| Peak Wavelength | 808nm |
| Optical Power | 2W |
| Iop | 2.6A |
| Beam Angle | 25° |
| Emission Mode | Multimode |
| PackagingType | 3535, 7060 |
