Stable nanosecond electro-optic Q-switched DPSS lasers for laser ranging, Raman spectroscopy, LIBS, material processing, nonlinear optics, and scientific research.
QEOS Series
Description
The QEOS Series Electro-Optic Q-Switched DPSS Pulsed Lasers deliver stable nanosecond pulses with high peak power, excellent beam quality, and reliable pulse-to-pulse performance. Available at 532nm and 1064nm with adjustable repetition rates from 1Hz to 1kHz, the series provides a compact and dependable solution for scientific research, spectroscopy, laser ranging, and industrial applications requiring precise pulsed laser output.
Features
- Wavelengths: 532nm & 1064nm
- Electro-optic Q-switched operation
- Nanosecond pulse width
- Repetition rates from 1Hz to 1kHz
- High peak power and pulse energy
- Excellent beam quality
- Low timing jitter
- Stable pulse-to-pulse energy
- Compact, air-cooled design
- Long operational lifetime
Applications
- Laser ranging
- Raman spectroscopy
- LIBS (Laser-Induced Breakdown Spectroscopy)
- ICP-MS
- Material processing
- Scientific research
- Nonlinear optics
- Laboratory instrumentation
Additional information
| Laser Technology | DPSS |
|---|---|
| Wavelength | 532nm, 1064nm |
| Pulse Energy | 2-40 mJ |
| Pulse Width | 6ns, 8ns |
| Repetition Rate | 1 Hz-1 kHz |
| Output Power | Up to 300mW |
Documentation
Data Sheet
[PDF] QEOS Series Electro-Optic Q-Switched Nanosecond DPSS Pulsed Lasers Datasheet
